WP01D– Differential Pressure Sensor
WP01D– Differential Pressure Sensor
Categories: Wireless Sensors
Typical Industries:
Brochure
- Hydrogen/ LNG/ CNG
- Water and wastewater
- Oil and Gas
- Agriculture
- Chemical Industry
- Pressurized vessel monitoring
- Cryogenic pressure
- Tubing and Casing pressure
- Line and Ground pressure
Brochure
Product Descriptions:
Monitor pressure vessel levels safely and accurately with the WP01D Differential Pressure Sensor. Certified C1D1 Group A, built for hazardous environments, and configurable in psi or Inches of H₂O, it delivers near real-time wireless readings with a 3-second update rate and 5-year battery life. Need to handle extreme cold? Optional cryogenic temperature capability ensures your data never stops.
WP01D: Precision. Durability. Real-time insight.
Product Information
| Product Dimensions: 121mm H, 46mm Diameter | Operating Temp: 40C to 65C, Storage -50C to 80C | Optional: -40C->85C | |
| Model Number: | |
| Wireless Communication: | Wireless Mesh Communication: Wireless comms to a LevelCon |
| Sensing Technology: | Seal Silicone |
| Operating Voltage: | 3.3 VDC |
| Operating Signal: | I2C |
| Output Signal: | Bluetooth 5.2 Low Energy with Long Range |
| Enclosure Material: |
|
| Range: | 0-290 psi, 0-200” H2O |
| Battery Size: | 2x AA (L91) Energizer Ultimate Lithium |
| Tank Connection: | 1/4” FNPT ports, High and Low side |
| CPU: | NA |
| Country of Origin | More than 50% assembled in the USA |
Warranty & Support
All our products come with a 1-year limited warranty and lifetime technical support. For any queries or issues, contact our support team.
